8" 2-Way Coaxial Speaker with 60 Watt Transformer

Model 8CXT60 is a 150 watt loudspeaker that combines an 8" diameter, low frequency transducer and a 1" exit, true compression driver.

The unit features a curvilinear, polypropylene cone for lower harmonic distortion, and a built-in crossover network for proper frequency transition between the two reproducers.

Model 8CXT60 operates within a frequency response range of 48 Hz to 18 kHz (±10dB) with a sensitivity of 92dB and a dispersion angle of 90°.

Model 8CXT60 includes a factory installed, high efficiency, 60W, 70.7/100V step down line transformer. Power taps are provided at 7.5, 15, 30 and 60 Watts (@70.7V).

Depth: 8 1/4" (20.955 cm)
Diameter: 8" (20.32 cm)
Shipping Weight: 13.25 lbs (6.01 kgs)
Frequency Response: 33 Hz to 21 kHz (±2dB)
Power Taps: 7.5, 15, 30, 60
Speaker Type: Compression Driver Coaxial
Sensitivity: 92dB (at 1W / 1M)
