Bi-Amp

4.25" Two-way, Thin-edge Ceiling Loudspeaker, with Back Can

Brand: Bi-Amp
Model: CM20DTS
UPC: 5420035208007
  • loudspeaker system
    2-way
  • woofer size
    4.25 inch
  • 70V transformer power taps
    20 - 10 - 5 - 2.5 - 1.25 watts
  • impedance
    16 ohms
  • low impedance dynamic power
    60 watts
Please log in to see your price
Specification Sheet Specification Sheet

Related products

Model: CM800I-WH
Please log in to see your price
Model: CM82-EZS-II-WH
Please log in to see your price
Model: CM62-BGM-II-WH
Please log in to see your price
Model: CM60DTD
Please log in to see your price
Model: CM600I-WH
Please log in to see your price
Model: CM400I-WH
Please log in to see your price
Model: CM82-EZ-II-WH
Please log in to see your price
Model: CM42-EZS-II-WH
Please log in to see your price

Customers who bought this product also purchased

Model: D-VOL30
Please log in to see your price

Product Properties

  • 70 volt
  • 1
  • 70V transformer power taps watts
  • 20 - 10 - 5 - 2.5
    20 - 10 - 5 - 2.5 - 1.25
  • applicable in 70V
  • yes
  • applicable low impedance
  • yes
  • closest RAL colour (subject to deviations)
  • RAL9010
  • colour
  • white
  • cutout in.
  • 7.6
  • depth in.
  • 3.31
  • frequency response Hz
  • 80 - 20K
  • grille main material
  • steel
  • Horizontal dispersion angle 1000 Hz
  • 180°
  • impedance ohms
  • 16
  • installation grip range in.
  • 0.12 - 1.61
  • IP rating
  • indoor use only
  • loudspeaker system
  • 2-way
  • low impedance
  • 1
  • low impedance dynamic power watts
  • 60
  • low impedance RMS power watts
  • 40
  • main construction material
  • ABS plastic
  • max SPL 1m dB
  • 104
  • mounting system
  • 2 screws
  • Net weight product lb.
  • 4.52
  • outside diameter in.
  • 8.78
  • SPL 1W/1m dB
  • 88
  • tweeter size inch
  • 1
  • Vertical dispersion angle 1000 Hz
  • 180°
  • woofer cone material
  • coated paper
  • woofer size inch
  • 4.25

Description:

The versatile CM20DTS 4.25" two-way built-in design loudspeaker produces a dynamic and warm sound that is ideal for high-quality background music and voice reproduction. The back can with only 83.5mm (3.287") built-in depth is the shallowest in the US market. The uncompromised sound quality and controlled sound performance makes it suitable for any kind of ceiling structure. The CM20DTS has a rotatable 70/100-volt power tapping selector on the front and offers 16 ohms connectivity. The thin-edge grill with integrated neodymium grille fixing magnets will guarantee an easy, smooth and elegant integration in any environment. Related Products: ALL REVAMP Power Amplifiers, All MA Series Mixer Amplifiers
