Control Contractor 6.5" In-Wall Speaker (70V)

The Control 126W is a premium in-wall speaker within the JBL Professional Control® Contractor line designed for applications such as foreground music, boardrooms, reception areas, airports, convention centers, cruise ships, retail outlets, restaurants, museums, surround locations, or any critical listening application where top performance from a loudspeaker with minimal visual impact is required.

Frequency Range : 38 Hz - 20 kHz
(-10 dB)

Power Capacity : 200 W Peak
100 W Continuous
Program Power
50 W Continuous
Pink Noise

Sensitivity : 88 dB SPL,
1W, 1 m (3.3 ft)

Transformer Taps : 70 V: 30 W, 15 W, 7.5 W & 3.7 W taps

Nominal Impedance : 8 ohms

Low Frequency : 165 mm (6.5 in) polymer-coated aluminum cone.

High-Frequency : 25 mm (1 in) pure-titanium dome with cloth suspension on low-diffraction swivel-mount with -10 degree aimability.

Terminations : Screw-down Euroblock-type connector. Max wire size 14 AWG (1.5 mm)2

Crossover Network : 3rd order (18 dB/oct) Low Pass to the woofer and 3rd order (18 dB/oct) High Pass to the tweeter.

Optimum Air Cavity Behind Speaker : 20 to 40 liters (0.7 to 1.4 cu ft)

Outside Dimensions (H x W x D) : 280 x 215 x 105 mm (11 x 8.5 x 4.1 in), 99 mm (3.8 in) front of wall to back of speaker.

Maximum Wall Thickness : 2 mm (1.25 in)

Cutout Size (H x W) : 246 x 181 mm (9.7 x 7.2 in),

Net Weight (ea) : 2.1 kg (4.5 lb)

Shipping Weight (ea) : 126 W: 4.8 kg (10.5 lb)

Included Accessories : Cutout template & paint shield

Optional Accessories : MTC-126RIF Rough-In Frame for new construction installation to wallstuds.
