DSR Series 15" 2-way Active Loudspeaker

Yamaha's revolutionary DSR Series of active loudspeakers take full advantage of our expertise and experience amassed as one of the world's leading pro audio manufacturers.

The DSR Series feature an ideal combination of advanced digital sound processing and the latest acoustic technologies for Integral Digital Tuning, plus our all-new D-CONTOUR multi-band dynamic processing for Intelligent Dynamic Control. Furthermore, they harness our next-generation high power Class-D amplifiers, featuring PFC switching mode power supply for Powerful Digital Drive while power supply, amplifiers, and transducers are continuously monitored by Extensive DSP Protection.

These core elements give the DSR Series the capability to deliver class leading power, extreme sound pressure levels and a listening experience that re-defines high definition audio. For loudspeakers you can count on to deliver the musicality and sound that will thrill audiences night after night, let the DSR Series power your performances to incredible new heights.

Frequency Range (-10dB): 45Hz ~ 20kHz
Frequency Response (-3dB): 55Hz ~ 18kHz
Coverage Angle: H90° x V60°
Crossover Type: FIR-X tuning (linear phase FIR filter)
Measured Maximum SPL (peak), IEC noise @ 1m: 136dB SPL

Controls: LEVEL control, LINE/MIC switch, HPF switch, D-CONTOUR switch, FRONT LED DISABLE switch, POWER switch

Input: XLR-3-31 x1 (Balanced), TRS Phone Jack x1 (Balanced)
Output: XLR-3-32 x1 (Balanced)
Power Consumption, 1/8 power: 100W
Weight: 28.0kg (62lbs)
