Sennheiser

SENN EW-DX EM 2 (Q1-9)

Brand: Sennheiser
Model: EW-DX EM 2 (Q1-9)
UPC: 615104361447
134 dB input dynamic range - no need to set gain on your wireless transmitters at all, thanks to proprietary Sennheiser Performance Audio Codec (SePAC)
AutoScan-feature quickly scans your environment and deploys frequencies with equidistant channel spacing - even without RF knowledge
Clear and easy focused user interface with OLED display, jog wheel navigation and control buttons
Equidistant channel spacing to easily allocate intermodulation-free channels: Standard Mode with 600 kHz spacing for up to 146 channels; Link Density (LD) Mode with 300 kHz spacing for up to 293 channels
Ethernet connectivity (IPv4 and IPv6)
Extended menu settings such as custom frequency list, selectable sync parameter and walk test
External PSU 12V/1A
Link Quality Indicator (LQI) showing the quality of the links separate to the RF levels
Low latency of 1.9 ms wireless transmission thanks to proprietary Sennheiser Performance Audio Codec (SePAC)
Network enabled for expanded remote control with Sennheiser Control Cockpit, Wireless System Manager (WSM - Available in 2023) and 3rd party media control systems via plug-in
Power over Ethernet (PoE IEEE 802.3af Class 3)
Remote control via Smart Assist App over Bluetooth® Low Energy (BLE) at distances up to 25 meters (Available in 2023)
Secure transmission of confidential content using AES 256 encryption
Selective headphone output with volume control on front panel
Two-channel digital half rack (9.5") in rugged metal housing
Up to 88 MHz switching bandwidth
Worldwide usage (specific frequencies subject to local RF regulations)
more
Please log in to see your price
Specification Sheet Specification Sheet
Specification Sheet (Download)
