Soundcraft

GB2 Series 24-Channel Mixing Console

Brand: Soundcraft
Model: GB2 24CH 24+2/4/2
UPC: 688705210759
100Hz high pass filter
100mm faders
12 busses
12-segment LED metering
2 full feature stereo channels
2 stereo returns (on stereo channels)
4 sub groups (paired)
6 Aux sends
6x2 output matrix
Direct outputs on every channel
GB30 mic preamp and precision equalisation circuitry
Record output
Switchable 48V phantom powering on every channel
Talkback facility
Please log in to see your price
Specification Sheet Specification Sheet

Related products

Customers who bought this product also purchased

Product Properties

  • Product Type
  • Analog Mixer

Description:

The GB2 is the latest addition to the Soundcraft GB Series, featuring 4 group busses configured as 2 stereo subgroups and an integral 6 x 2 matrix.

Intended for installed-sound and Audio-Visual applications that do not require the functionality provided by the GB4 or GB8, the GB2 is available in frame sizes of 16, 24 and 32 mono inputs, each with 2 stereo inputs as standard. Each input features the high-performance GB30 Mic Pre and GB30 Equaliser designs of the GB4 and GB8, along with 6 Aux buses.

Four Subgroups are provided as two stereo pairs, with a unique facility for adjusting the width of the stereo signal across the stereo mix. The channel pan settings are retained on the group outputs, while the degree of stereo separation to the mix bus is independently adjustable from full stereo through to mono.

The GB2 also features two stereo input channels, with separate mic and line inputs. In normal use, the mic inputs are routed to the local channel and the line inputs act as a stereo return to the mix bus. Selecting the LINE input to the local channel overrides the Mic inputs.

Analogue/Digital: Analogue
Frame Size: 24
Stereo Channels: 2
Digital I/O: No
FX Processors: 0
Groups: 4
EQ Bands: 4
Aux Sends: 6
Returns: 1
Direct Outputs: Yes
Matrix Outputs: 2
Main Bus Out: LR
