Peerless

Pivot Wall Mount For 22"-40" Flat Panel Displays

Brand: Peerless
Model: SP740P
UPC: 735029237341
Compatible with 22" to 40" flat panel displays with mounting hole patterns of 75,100, 200 x 100, and 200 x 200mm
Display can be held as close to the wall as 2.99" (76mm) or be extended as far as 11.8" (299mm)
Display can be pivoted a full ±90° for obtaining ideal viewing direction
Integrated cable management system makes running cables simple while keeping the cables protected
One-touch tilt mechanism provide up to 15°/-5° of tilt adjustment for achieving the ideal viewing angle
UL Listed for up to 80lb (36kg) load capacity
±5° of roll allow for post installation leveling
more
Please log in to see your price
Specification Sheet Specification Sheet
Specification Sheet (Download)

Customers who bought this product also purchased

Product Properties

  • Bullet points
  • Compatible with 22" to 40" flat panel displays with mounting hole patterns of 75,100, 200 x 100, and 200 x 200mm
    Display can be held as close to the wall as 2.99" (76mm) or be extended as far as 11.8" (299mm)
    Display can be pivoted a full ±90° for obtaining ideal viewing direction
    Integrated cable management system makes running cables simple while keeping the cables protected
    One-touch tilt mechanism provide up to 15°/-5° of tilt adjustment for achieving the ideal viewing angle
    UL Listed for up to 80lb (36kg) load capacity
    ±5° of roll allow for post installation leveling
  • Product Type
  • AV Mount

Description:

Matching elements of easy installation and user-friendliness are found in this pivot mount. It boasts a low-profile wall plate design that easily attaches to the wall with only two screws. This pivot arm extends away from the wall with ease and closes back up to save space. The arm’s multiple pivot points allow the flat panel display to pivot, tilt and roll for the perfect viewing angle adjustment and display leveling. Its fully integrated cable management system eliminates unsightly cable clutter and provides a safeguard. Designed and built in the USA, this mount maintains the same brilliant look as the entire SmartMount® 700 Series line of articulating wall mounts and pivot wall mounts.

(One PLP adapter plate is required to complete the installation.)

Minimum to Maximum Screen Size: 22" to 40"
VESA Pattern: 75 x 75, 100 x 100, 200 x 100, 200 X 200
Mounting Pattern: 75 x 75, 100 x 100, 200 x 100, 200 X 200mm (2.95 x 2.95, 3.94 x 3.94, 7.87 x 3.94, 7.87 x 7.87")
Weight Capacity: 80lb (36.0kg)
Color: Black
Finish: High Gloss
Security Features: Non-Security Hardware
Tilt: +15 / -5
Swivel Yaw: +90 / -90
Roll: +5 / -5
Distance from Wall: 2.99 - 11.80" (76 - 299mm)
Product Dimensions: 14.24 x 9.35 x 2.99 - 11.80" (362 - 349 x 237 x 76 - 299mm)
Ship Dimensions: 10.125 x 4.25 x 12.625" (257.2 x 108.0 x 320.7mm)
Shipping Weight: 5.5lb (3.8Kg)
