Electro Voice

Composite 12“ Two-Way Speaker with 70V Transformer (Weatherized, White)

Model: SX300PIX-W
UPC: 800549682374
Products Variants:
1.25” voice coil (titanium diaphragm)
4 x M8x1.25 attachment inserts
HF-horn features Varipath™
High Sensitivity
Integral 70/100V transformer
PRO™ Driver protection circuit
Trapezoidal (25° per side)
Ultra-linear frequency response
Vented LF enclosure
more
Please log in to see your price
Specification Sheet Specification Sheet
Specification Sheet (Download)

Related products

Customers who bought this product also purchased

Product Properties

  • Active/Passive
  • 303
  • Bullet points
  • 1.25” voice coil (titanium diaphragm)
    4 x M8x1.25 attachment inserts
    HF-horn features Varipath™
    High Sensitivity
    Integral 70/100V transformer
    PRO™ Driver protection circuit
    Trapezoidal (25° per side)
    Ultra-linear frequency response
    Vented LF enclosure
  • Coverage
  • 65° x 65°
  • Frequency Range
  • 50Hz-20kHz (-10dB)
  • HF Driver Size
  • 1.25"
  • LF Driver Size
  • 12"
  • Max Dimensions
  • 23.07" x 16.89" x 12.28"
  • Max SPL
  • 131dB
  • Nominal Impedance
  • 70/100V
  • Product Type
  • PA Loudspeaker
  • Sensitivity
  • 99dB
  • System Power
  • 200,140,100,70,50

Description:

Weatherized, 70/100v permanent installation version of the SX300E, a 12“ composite two-way considered to be the world‘s best lightweight, high power speaker system. Designed for distributed systems.

Chassis Size: 304.8 mm (12")
Color: White
Directivity Index: 11.1 dB
Input Connections: Four-pin Speakon (2)
Speaker Type: Fullrange
Speaker Type: Mid-High
Speaker Type: Two-Way
Frequency Response (-10 dB): 50 - 20000 Hz
Internal Crossover: Yes
Sensitivity 1 W/1 m: 99 dB
Max. SPL/1m (calc): 131 dB
Coverage (Nominal -6 dB) H: 65 °
Coverage (Nominal -6 dB) V: 65 °
System Power Handling: 300 Watts
LF Transducer: DL12BFH
HF Transducer: DH2010
Crossover Frequency: 1500 Hz
Nominal Impedance (Passive): 8 ?
Minimum Impedance: 6 ?
Flying: Yes
Outdoor: Yes
Height: 586 mm (23.07")
Width: 429 mm (16.89")
Depth: 312 mm (12.28")
Weight Net: 14.5 kg (31.97 lbs)
