8" Surface Mount Speaker Assembly

The QUAM SYSTEM 1 is a complete loudspeaker assembly with an industry standard 8” O.D., full range speaker, 5W- 25/70.7V pigtail transformer, 22 gage steel baffle and 16 gage square steel enclosure.
Finish: White baked epoxy hybrid.

INTENDED USE
Indoor environment
Program Material: Signal tones, voice and music

Average Sensitivity: 92dB SPL, 1W/ 1M
Power Rating: 12W RMS, EIA 426A Standard
Calculated Output: 99 dB SPL, 5W/ 1M
Frequency Response: 65 Hz - 17 kHz
Nominal Coverage Angle: 90° Included Angle, -6 dB / 2 kHz, Half space
Audio Connection: 7” long, color-coded tinned wires, pre-cut
