Omni-Purpose Loudspeaker with Transformer

The Model AP-30T is a double re-entrant loudspeakers which deliver 30-watts of continuous power handling, superior intelligibility and unparalleled efficiency.

The AP-30T operates within a nominal frequency response range of 300-12,000 Hz and offers a sensitivity of 121dB at rated power to provide clear voice and signal communication.

The trademarked squared-bell design signifies Atlas Sound quality and reliability. The Omni-Purpose® mounting bracket (supplied on all models) achieves precise positioning in the vertical and horizontal planes with a single adjustment and includes provisions for loudspeaker installation on conventional surfaces as well as for strap mounting on I-beams or pillars.

AP Series loudspeakers are U.S. made to assure superior service reliability. Weather-resistant construction is metal and matching ABS plastic with metal components finished in grey epoxy.

Height: 11" (27.94 cm)
Width: 10" (25.4 cm)
Depth: 10 1/2" (26.67 cm)
Shipping Weight: 6.30 lbs (2.86 kgs)
Frequency Response: 300-12,000 Hz
Power Taps: 2, 3.8, 15, 30 @ 70.7V
Dispersion: 60°
Power Rating: 30 Watts
Sensitivity: 108dB
Operating Range: -40 to 70C
