Atlas Sound

4" 2-Way Speaker Low Profile System with Transformer (White)

Model: FAP42TC
UPC: 612079181209
Products Variants:
"Press fit" grilles blend better into contemporary architecture
Easy installation in drop tile or sheetrock ceilings via C-ring/V-rail tile bridge and "dog leg" mounting system (included)
Enhanced quality 70.7V/100V internal transformers minimize insertion loss and maintain low frequency response while providing increased output for higher SPL applications
Front mounted tap selector switch for easy system tuning adjustments includes transformer bypass setting for 8 ohm direct coupled operation
Low depth (4") speaker system for limited space applications
UL 1480
Please log in to see your price
Specification Sheet Specification Sheet

Related products

Customers who bought this product also purchased

Model: PA40G
Please log in to see your price

Product Properties

  • Product Type
  • Ceiling Speaker

Description:

With an overall depth of 4" (102mm) the FAP42TC is the perfect choice when high fidelity audio and wide, even coverage is required but space above the plenum is limited. For wall mount applications (tanning salons or surround sound) the short 4" depth will even work in most stud wall installations. A simplified input section features a 4-pole Phoenix style connector for easy daisy chaining between speakers. A simple cover including combination 1/2" (13mm) / 3/4" (19mm) knock-outs is provided for installation ease. The popular Atlas Sound "C-ring / V-Rail" mounting system is provided for quick installation into drop tile acoustic ceilings and existing construction drywall. For new construction drywall applications the optional FAP42-TR may be used. All other popular features of the FAP42T are included on the new FAP42TC including the front mounted tap selector switch (which included transformer bypasss for 8 Ohm applications), attractive press-fit grills, high performance 4" polypropolene cone driver with 3/4" (19mm) PEI tweeter and precision crossover components for smooth, even coverage.

Depth: 4 1/4" (10.7696 cm)
Diameter: 10 1/2" (26.67 cm)
Shipping Weight: 13.00 lbs (5.90 kgs)
Frequency Response: 75Hz - 20kHz
Power Taps: 1W, 2W, 4W, 8W, 16W & 8O
Speaker Type: Coaxial
Dispersion: 130°
Sensitivity: 88dB Average
UL Listed/Standard: 1480
