Atlas Sound

4" 2-Way Speaker System with Transformer (White)

Model: FAP42T
UPC: 612079179824
Products Variants:
4 Pole detachable "phoenix" style connector allows easy pre-wiring and is convenient for daisy chaining additional Strategy full range speakers or subwoofers
Easy installation in drop tile or sheetrock ceilings via C-ring/V-rail tile bridge and "dog leg" mounting system (included)
Easy installation in drop tile or sheetrock ceilings via C-ring/V-rail tile bridge and "dog leg"mounting system (Included)
Enhanced quality 70.7V/100V internal transformers minimize insertion loss and maintain low frequency response while providing increased output for higher SPL applications
Extended low frequency response from the 285 cubic inch optimally tuned and ported deep drawn galvanized steel enclosure
Front mounted tap selector switch for easy system tuning adjustments includes transformer bypass setting for 8 ohm direct coupled operation
Perfect companion with the FAPSUB subwoofer system when sub bass is required
Press-fit grille blends perfectly into contemporary architecture
Please log in to see your price
Specification Sheet Specification Sheet

Related products

Customers who bought this product also purchased

Model: MS7701B
Please log in to see your price
Model: MS7201B
Please log in to see your price
Model: SLXD1=-J52
Please log in to see your price
Model: 122SLBK
Please log in to see your price
Model: BSSBLU100M
Please log in to see your price
Model: GXD8
Please log in to see your price

Product Properties

  • Product Type
  • Ceiling Speaker

Description:

FAP42T combines superior coaxial loudspeaker performance with wide dispersion and easy
installation.

A low profile enclosure and wide coverage make the FAP42T a perfect choice for low ceilings.

The FAP42T will satisfy the needs of owners, architects, contractors, and consultants by
delivering true, high fidelity sound reproduction in an attractive and easy-to-install system.

The FAP42T is ideal for high-intelligibility voice, music, and signal reproduction in commercial, industrial,
and institutional applications.

Depth: 8 7/8" (22.5425 cm)
Diameter: 10 1/2" (26.67 cm)
Shipping Weight: 12.00 lbs (5.44 kgs)
Frequency Response: 75Hz - 20kHz
Power Taps: 1W, 2W, 4W, 8W, 16W & 8Ohm
Speaker Type: Coaxial
Dispersion: 130°
Sensitivity: 88dB Average
UL Listed/Standard: 1480
