Pre-Assembled Baffle, 5 oz Loudspeaker w/ 5W Transformer

Model FD70W is a cost effective assembly that include high-quality 8" loudspeaker, 70.7V transformer and screw type grill. Unit is shipped assembled, ready for installation.

The FD70W features a conventional cone design loudspeaker with a 1" diameter voice coil to reproduce voice and music with excellent response and superb overall performance.

Speaker / transformer is factory installed on a 62-8 style baffle.

Depth: 2 5/8" (6.6675 cm)
Diameter: 8" (20.32 cm)
Shipping Weight: 3.67 lbs (1.66 kgs)
Frequency Response: 100 Hz - 10 kHz, ± 1.5dB
Power Taps: .5, 1, 2, 5
Speaker Type: Treated Paper
Dispersion: 105°
Sensitivity: 97dB Peak, 94dB Average
