Call Signal Flasher

New LED design with dimmer. Provides both a visual and audible indication of a call signal on the intercom channel. Frontpanel mode switch selects flasher, ring or both. Allows control of both tone volume and light brightness.

Flash Rate
2 times/sec

Flasher Lens
2.5" diameter red

Rear Panel Connectors
One each XLR-3F and XLR-3M

Power Requirements
Input Voltage: 20-30 VDC
Input Current: (idle) <= 10mA
Input Current: (max) <= 90mA

Front Panel Controls & Indicators
Brightness Control
Three-way switch for flash and tone
Tone level control
Speaker

Environmental
32? to 122?F (0? to 50?C)

Dimensions
2.5" H x 4" W x 5.0" D
(63 x 101 x 127 mm)

Weight
0.91 lbs. (0.415 kg)
