Atlas Sound

8" High Efficiency Pendent Mount Speaker (White)

Model: PM8GD-WH
UPC: 612079188482
Products Variants:
5 Meters of 2mm Cable & Mounting Hardware Included
70.7V taps @ 1, 2, 4, 8 Watts and 8Ohm direct input via concealed terminal block
8" GD87 driver provides 120 degree (60 degree off-axis) coverage in the 2kHz octave band
Compatible with standard 3/4" ceiling fan hardware
Extreme high efficiency (96dB 1W/1M) allows for lower tap settings and more loudspeakers per amp channel in many installations
Please log in to see your price

Related products

Extended Range Full-Range Pendant Speaker (White)
Extended Range Full-Range Pendant Speaker (White)
Model: C67P/T-WH
Brand:JBL
Please log in to see your price
View
Narrow 75° Coverage High Ceiling Pendant Speaker (White)
Narrow 75° Coverage High Ceiling Pendant Speaker (White)
Model: C67HC/T-WH
Brand:JBL
Please log in to see your price
View
Compact Full-Range Pendant Speaker
Compact Full-Range Pendant Speaker
Model: C65P/T
Brand:JBL
Please log in to see your price
View
8″ 2-way Pendent Mount Speaker (White)
8" 2-way Pendent Mount Speaker (White)
Model: PM8FA-WH
Brand:Atlas Sound
Please log in to see your price
View
8″ 2-way Pendent Mount Speaker
8" 2-way Pendent Mount Speaker
Model: PM8FA-B
Brand:Atlas Sound
Please log in to see your price
View
4″ 2-way Pendent Mount Speaker
4" 2-way Pendent Mount Speaker
Model: PM4FA-B
Brand:Atlas Sound
Please log in to see your price
View
4″ 2-way Pendent Mount Speaker (White)
4" 2-way Pendent Mount Speaker (White)
Model: PM4FA-WH
Brand:Atlas Sound
Please log in to see your price
View
8″ High Efficiency Pendent Mount Speaker
8" High Efficiency Pendent Mount Speaker
Model: PM8GD-B
Brand:Atlas Sound
Please log in to see your price
View

Customers who bought this product also purchased

Product Properties

  • Bullet points
  • 5 Meters of 2mm Cable & Mounting Hardware Included
    70.7V taps @ 1, 2, 4, 8 Watts and 8Ohm direct input via concealed terminal block
    8" GD87 driver provides 120 degree (60 degree off-axis) coverage in the 2kHz octave band
    Compatible with standard 3/4" ceiling fan hardware
    Extreme high efficiency (96dB 1W/1M) allows for lower tap settings and more loudspeakers per amp channel in many installations
  • Product Type
  • Ceiling Speaker

Description:

Model PM8GD-B uses the popular Atlas Sound GD series coaxial driver to provide familiar response and high efficiency while retaining economy when high density speaker counts are required in page only applications.

Height: 16 5/8" (42.2148 cm)
Diameter: 12 1/4" (31.115 cm)
Shipping Weight: 14.00 lbs (6.35 kgs)
Power Taps: 1, 2, 4, 8 Watts and 8O
Speaker Type: Coaxial (Treated Paper)
Dispersion: 105° (2kHz Octave Band, -6dB Points)
Power Rating: 16 Watts
Sensitivity: 96dB Average
