Atlas Sound

4" 2-way Pendent Mount Speaker

Model: PM4FA-B
UPC: 612079183517
Products Variants:
3 Meters of 2mm Cable & Mounting Hardware Included
4" FA134 driver provides 130 degree (65 degree off-axis) coverage in the 2kHz octave band
70.7V taps @ 1, 2, 4, 8 and 16 Watts plus 8-ohm direct input via concealed terminal block
Compatible with standard 3/4" ceiling fan hardware
Discreet, attractive enclosure
Please log in to see your price

Related products

Model: C65P/T
Please log in to see your price

Customers who bought this product also purchased

Model: FAP42-TR
Please log in to see your price

Product Properties

  • Bullet points
  • 3 Meters of 2mm Cable & Mounting Hardware Included
    4" FA134 driver provides 130 degree (65 degree off-axis) coverage in the 2kHz octave band
    70.7V taps @ 1, 2, 4, 8 and 16 Watts plus 8-ohm direct input via concealed terminal block
    Compatible with standard 3/4" ceiling fan hardware
    Discreet, attractive enclosure
  • Product Type
  • Ceiling Speaker

Description:

Model PM4FA-B uses the familiar response and dispersion of Atlas Sound's model FA134 high performance 4" Strategy Series® driver. This loudspeaker is the same FA series device used in Atlas Sound's popular FAP42T in-ceiling speaker package. Mounted down-firing in an attractive enclosure, the PM4FA provides natural sounding, wide coverage for low height installations while retaining very impressive full range frequency response for both music and paging applications.

Height: 13 7/8" (35.2298 cm)
Diameter: 9 1/4" (23.495 cm)
Shipping Weight: 10.00 lbs (4.54 kgs)
Power Taps: 1, 2, 4, 8, 16 and 8 ohms
Speaker Type: Coaxial
Dispersion: 130°
Power Rating: 25 Watts
Sensitivity: 88dB Average
