Atlas Sound

14RU Mobile Equipment Rack with Doors (25.5" Deep)

Model: RX14-25SFD
UPC: 612079185986
Products Variants:
16-ga. CRS Frame Manufactured to E.I.A. Standards
Four, 4" Heavy-Duty Casters (175 lb. cap./ea.)
Includes 1 Pair Adjustable, 11-ga., Front-to-Rear Mounting Rails
Mounting Rail Supports with Slotted Cut-Outs for Vertical Wire Management
Perforated Front and Rear Top Flanges, Sides and Rear Door Provide Ventilation and Dissipation of Equipment-Generated Heat
Removable Front and Rear Doors (Right or Left-Hand Hinging) are Identically Keyed for Security and Convenience
RR14 optional rear mounting rails available
Rubber-Padded Steel Grip "Road Handles" (2 Per Side)
Standard Rack Includes Base, Top Panel, Side Panels, Casters, Front and Rear Doors
Three, Wire Isolation Holes Located on Bottom of Rear Panel for External Wire Access
Welded Frame for Long-Lasting Durability
Please log in to see your price
Specification Sheet Specification Sheet

Related products

Model: SRK12
Please log in to see your price
Model: SRK8
Please log in to see your price
Model: SRK16
Please log in to see your price

Customers who bought this product also purchased

Product Properties

  • Product Type
  • Rack Case

Description:

The RX14-25SFD mobile cabinet is ruggedly constructed of 16-ga. CRS and includes heavy-duty casters. Equipped with a front pair of 11-ga., CRS adjustable mounting rails tapped 10–32 on standard E.I.A. 5/8"- 5/8"-1/2" spacing.

Optional RR14 rear mounting rails are available for additional support. Front-to-rear mounting rail supports have slotted cutouts to easily adjust rail depth and to provide open raceways for containing vertically run wire and cable.

Cabinet is 25 1/2" deep and has a vertical panel space height of 24-5/8". It features one pair of recessed, hinged, and rubber-padded steel grips on each side (four total) for transport convenience. Easy wiring access is provided through three wire isolation holes (two, 1 1/2" dia., and one oblong 1-1/2" x 3") in the rear base flange.

The units’ four, oversized, heavy-duty casters, two of which are locking, ensure smooth mobility, and have a load capacity of 175 lb. each – 700 lb. total weight capacity.

Also include vented and removable locking doors, as well as vented top-front and top-rear flanges. Surface mounting front door is 1" deep to provide clearance for equipment knobs and handles which protrude up to 1-1/2" from the front of the rail.

Cabinet is finished in #962 black epoxy.

Rack Spaces: 14
Height: 33 9/16" (85.25002 cm)
Width: 22 5/16" (56.67502 cm)
Depth: 25 1/2" (64.77 cm)
Usable Depth: 24" (60.96 cm)
