14RU Mobile Equipment Rack, No Doors (30" Deep)

The RX14-30 mobile cabinet is ruggedly constructed of 16-ga. CRS and includes heavy-duty casters. Equipped with a front pair of 11-ga., CRS adjustable mounting rails tapped 10–32 on standard E.I.A. 5/8"- 5/8"-1/2" spacing.

Optional RR14 rear mounting rails are available for additional support. Front-to-rear mounting rail supports have slotted cutouts to easily adjust rail depth and to provide open raceways for containing vertically run wire and cable.

Cabinet is 30" deep and has a vertical panel space height of 24-5/8". It features one pair of recessed, hinged, and rubber-padded steel grips on each side (four total) for transport convenience. Easy wiring access is provided through three wire isolation holes (two, 1 1/2" dia., and one oblong 1-1/2" x 3") in the rear base flange.

The units' four, oversized, heavy-duty casters, two of which are locking, ensure smooth mobility, and have a load capacity of 175 lb. each – 700 lb. total weight capacity.

Shown with optional front door: SFD14.

Cabinet is finished in #962 black epoxy.

Depth: 30" (76.2 cm)
Rack Spaces: 14
Width: 22 5/16" (56.67502 cm)
Usable Depth: 28.5" (72.39 cm)
Height: 33 9/16" (85.25002 cm)
