8" Dual Cone Sound Masking Speaker with 4W Transformer and Enclosure

The M1000 sound masking speaker assembly is designed to accurately reproduce the required spectrum of masking signal into the plenum space. The innovative 734 cubic inch square enclosure ensures ample low frequency response. A specially designed 8" dual cone loudspeaker is included in the package. A high efficiency 70.7V internal transformer is coupled to an external tap selector switch for easy system tuning.


The exclusive Atlas Sound EZ hang brackets simplify installation. This innovative suspension system utilizes (2) collapsible plated hangers configured to allow quick upward, downward, or side firing installation. The hangers are factory-installed on the unit and fold flat for shipping. To meet most any local code requirement, the M1000 includes an innovative cover containing both knockouts and a strain relief. This system will allow the use of rigid or flexible conduit (if required) and easily accommodates "through" connections on the removable plate. UL 2043 listed for use in air handling spaces.

Height: 5 1/2" (13.97 cm)
Width: 110 9/16" (29.37002 cm)
Depth: 110 9/16" (29.37002 cm)
Shipping Weight: 10.00 lbs (4.54 kgs)
Frequency Response: 100 Hz - 10 kHz, ± 1.5dB
Power Taps: .25, .5, 1, 2 and 4
Speaker Type: 8" Dual Cone
Dispersion: Upward, Downward, Horizontal
Sensitivity: 97dB Peak, 94dB Average
ETL Listed/UL Standard: 1480, 2043
