12" Indoor / Outdoor Horn Loaded System (60° x 60°)

The R.5-66Z two-way, full-range loudspeaker system is engineered to provide quality full-range sound projection in a variety of outdoor and indoor applications. Its wide range, smooth frequency response and high efficiency ensure both high fidelity music reproduction and superb projection of clear intelligible speech with very low distortion. Five-year limited product warranty; fifteen-year enclosure warranty.

Loudspeaker Type: 2-way, horn loaded, coaxial, weather-resistant
Operating Range: 125 Hz to 10 kHz (±4 dB)
Max Input Ratings: 200W continuous, 500W program
Maximum Output: 126 dB SPL / 133 dB SPL (peak)
Nominal Impedance: 8 ohms
Nominal –6dB Beamwidth: 60°H x 60°V
Input Connection: 16-2 SJOW (12 ft /4 m)
Enclosure: Rotomolded LLDPE, light grey
Mounting/Rigging Provisions: (5) 3/8-16 rigging points
Environmental Performance: IEC529 IP55W rating with a minimum 5-degree downward aiming angle
Supplied Accessories: (1) Yoke bracket, (1) Aiming strap
