Community Professional Loudspe

12" 3-Way Indoor / Outdoor System with Transformer

Model: R.5HPT
UPC: 617174007164
Products Variants:
Corrosion-resistant zinc-rich epoxy dual-layer powder coated steel grille and yoke
DYNA-TECH protection circuitry
High efficiency
High power passive crossover
Integral mounting points
Multi-tap 200W autoformer for 70V and 100V inputs
Pattern control down to 630 Hz
Weather-treated drivers and crossovers
Please log in to see your price
Specification Sheet Specification Sheet

Customers who bought this product also purchased

Product Properties

  • Product Type
  • Surface Mount Speaker

Description:

The R.5HPT is a three-way horn loaded weather-resistant loudspeaker system engineered to provide maximum intelligibility from a most compact design. By the packaging of Community's well-known M200 midrange driver coaxially within the mouth of the 12" LF horn, an extremely powerful tool for voice announcement systems was created. High frequencies are handled by Community's non-metallic diaphragm UC1 1" exit HF driver. An input autoformer with switchable taps provides impedance matching to 70V or 100V lines. The M200/UC1 creates effortless voice-power with HF sparkle that must be heard to be appreciated. No longer do audiences need to experience the unpleasant sound of "honky" re-entrant paging horns. The R.5HP can act as both a musical entertainment loudspeaker and a voice PA loudspeaker simultaneously. Each system is backed by Community's five-year product warranty and fifteen-year enclosure warranty.

Loudspeaker Type: 3-way, horn loaded coaxial, weather-resistant
Operating Range: 125 Hz to 12500 Hz (± 6 dB)
Max Input Ratings: 200W, 70V/100V
Maximum Output on 200W Tap: 128 dB SPL
Nominal Impedance: 25 ohms
Nominal –6dB Beamwidth: 60°H x 40°V
Input Connection: 16-2 SJOW (12 ft /4 m)
Enclosure: Rotomolded LLDPE, light grey
Mounting/Rigging Provisions: (5) 3/8-16 rigging points
Environmental Performance: IEC529 IP55W rating with a minimum 5-degree downward aiming angle
Supplied Accessories: (1) Yoke bracket, (1) Aiming strap
