Atlas Sound

24W Two Channel Power Amplifier

Model: TSD-PA122G
UPC: 612079187843
Products Variants:
12W @ 4Ohms x 2 Channels
Balanced Stereo Inputs
Bridgeable to 24W at 8O Mono Output
Input Signal & Peak Indicator LED's
Meets Energy Star Standards
Removable Phoenix Style I/O Connectors
Security Covers Included for All Front Panel Controls
Unbalanced Stereo Inputs Via Dual RCA Connectors
Please log in to see your price

Related products

Model: TSD-ML22VCA
Please log in to see your price
Model: TSD-ML11
Please log in to see your price

Customers who bought this product also purchased

Product Properties

  • Product Type
  • Install Amplifier

Description:

The TSD-PA122G 4? stereo amplifier is perfectly suited for almost any general amplification requirement. Perfect for adding sound reinforcement to small projector systems as it provides ample power to drive up to four 8? loudspeakers in a classroom or boardroom application.

Output is 12W per channel at 4? or 24W bridged mono at 8?. Input is via balanced stereo phoenix style and unbalanced RCA connectors. Front panel gain controls provide adjustment for both left/right or bridged outputs and include removable knobs.

Power Output: 12W @ 4O x 2 CH, 6W @ 8O x 2 CH, 24W @ 8O Bridged
Unbalanced Input Impedance: 10KO
Input Level: 316mV (-10dBV)
Balanced Input Impedance: 10KO Balanced, 5KO Unbalanced
Line Input Level: 500mV (-6dBV) Balanced
Frequency Response: 20Hz - 20kHz (+/-3dB)
THD: 1% & 1kHz
Signal to Noise Ratio: 80dBV
24VDC Power Requirements: 500mA
