Electro Voice

Composite 12“ Two-Way (60°x60°)

Model: ZX3-60B
UPC: 800549682589
Products Variants:
Lightweight 12“ two-way loudspeaker
NL4 connectors
Seven M8 rigging points, two single stud fittings
Please log in to see your price

Related products

High Power 15″ Speaker (60°x60°, White)
High Power 15" Speaker (60°x60°, White)
Model: ZX5-60W
Brand:Electro Voice
Please log in to see your price
View
Composite 12“ Two-Way (90°x50°)
Composite 12“ Two-Way (90°x50°)
Model: ZX3-90B
Brand:Electro Voice
Please log in to see your price
View
Composite 15“ Two-Way
Composite 15“ Two-Way
Model: ZX4
Brand:Electro Voice
Please log in to see your price
View
High Performance 8″ Indoor/Outdoor Speaker (90°x50°)
High Performance 8" Indoor/Outdoor Speaker (90°x50°)
Model: ZX1I-90
Brand:Electro Voice
Please log in to see your price
View
High Performance 8″ Loudspeaker
High Performance 8" Loudspeaker
Model: ZX1-90
Brand:Electro Voice
Please log in to see your price
View
High Performance 8″ Indoor/Outdoor Speaker (90°x50°, White)
High Performance 8" Indoor/Outdoor Speaker (90°x50°, White)
Model: ZX1I-90W
Brand:Electro Voice
Please log in to see your price
View
ZX Series Compact 8″ Powered Loudspeaker
ZX Series Compact 8" Powered Loudspeaker
Model: ZXA1-90B-120V
Brand:Electro Voice
Please log in to see your price
View
12 inch passive subwoofer
12 inch passive subwoofer
Model: ZX1-SUB
Brand:Electro Voice
Please log in to see your price
View

Customers who bought this product also purchased

Product Properties

  • Active/Passive
  • 303
  • Bullet points
  • Lightweight 12“ two-way loudspeaker
    NL4 connectors
    Seven M8 rigging points, two single stud fittings
  • Coverage
  • 60° x 60°
  • Frequency Range
  • 48Hz-20kHz (-10dB)
  • HF Driver Size
  • 2"
  • LF Driver Size
  • 12"
  • Max Dimensions
  • 24.14" x 15.65" x 14.26"
  • Max SPL
  • 131dB
  • Nominal Impedance
  • 8Ω
  • Product Type
  • PA Loudspeaker
  • Sensitivity
  • 97dB
  • System Power
  • 600W Cont.

Description:

ZX3 offers an unprecedented level of lightweight 12“ two-way loudspeaker performance for the widest variety of portable and installed applications.

Color: Black
Speaker Type: Fullrange
Frequency Response (-3 dB): 58 - 15000 Hz
Frequency Response (-10 dB): 48 - 20000 Hz
Sensitivity 1 W/1 m: 97 dB
System Power Handling: 600 Watts
LF Transducer: DVX3121
Low Frequency Power Handling: 500 Watts
High Frequency Power Handling: 40 Watts
HF Transducer: ND2
Enclosure Material: Polypropylene
Weight Net: 19.8 kg (43.65 lbs)
